Series 3 F36

The Series 3 F36 is ruggedly built and packed with features to minimize operator effort, with sturdy cast iron linkages, easy hydrostatic controls, and the option of a foldable ROPS or heated cabin.

• Engine: TYM T1700N6
• Max Horsepower: 34.7 hp (25 kW)
• Displacement: 1715 cc | 104.7 cu in
• Rated Engine Speed: 2600 rpm
• Transmission: F36RN: F12xR12 / F36HN: 3-Range
• PTO: 540/540E rpm
• Hitch Lift Capacity: 1500 kg (3306 lb)
• Fuel Tank Capacity: 30 L | 7.9 gal
• Overall Length: 3380 mm | 133.1 in
• Weight: F36RN F-ROPS 1531 kg/3375 lb, ROPS 1519 kg/3349 lb; F36HN F-ROPS 1522 kg/3355 lb, ROPS 1510 kg/3329 lb
• Front Tires: 7-16 6PR / 8-16 4PR / 280/70R16 / 215/70R16
• Rear Tires: 11.2-24 8PR / 12.4-24 6PR / 380/85R24 / 44x18-20
