Series 3 T475

The T3047 (T475) steps up the Series 3 platform with a larger TYM engine and higher hitch lift capacity, offering the same compact maneuverability with added muscle for demanding jobs.

• Engine: TYM T2300N3
• Max Horsepower: 45.3 hp (34 kW)
• Displacement: 2287 cc | 139.5 cu in
• Rated Engine Speed: 2600 rpm
• Transmission: SS: F12xR12 / HST: 3-Range
• PTO: 540 rpm
• Hitch Lift Capacity: 1220 kg (2689.6 lb)
• Fuel Tank Capacity: 34 L | 9.0 gal
• Overall Length: ROPS 3400 mm | 133.9 in; Cab 3450 mm | 134.6 in
• Weight: 1565 kg | 3450.2 lb
• Front Tires: 8.0-16 4PR
• Rear Tires: 12.4-24 6PR
