Series 4 4820C

The cabbed 4820C brings enclosed, climate-controlled comfort to the 48 hp Series 4 platform.

• Engine: TYM T2300N2
• Max Horsepower: 48 hp (36 kW)
• Displacement: 139.5 cu in | 2286 cc
• Rated Engine Speed: 2600 rpm
• Transmission: 4820C: Synchromesh F16xR16 / 4820CH: HST 4-Range
• PTO: 540/750 rpm
• Hitch Lift Capacity: 3306 lb (1500 kg)
• Fuel Tank Capacity: 11.8 gal | 45 L
• Overall Length: 127.4 in | 3236 mm
• Front Tires: 9.5-16
• Rear Tires: 13.6-26
